Switch Matrices

MPG Solutions® offers a variety of customizable Switch Matrices designed specifically for military & defense applications.  Supplying the industries with ruggedized systems for 70+ years.


crossbar800x700

Overview

  • Designed and developed for commercial and military environments, our RF switch matrix solutions offer a variety of high density, RF Switching (Tx and Rx) configurations including low/high frequency, low/high power, narrowband and broadband solutions from DC to 50GHz. Units can be equipped with active or passive components in addition to any switches.

Benefits

Reliably routing the input signal to any output port, Switch Matrices are applicable for complex applications where multiple I/O signals increase switching complexity.

  • Situations where high-density RF switching (transmitting and receiving) for narrowband, low frequency and low power applications are required
  • Support for low power and high-density signal routing both on the transmitter (Fan-Out) and receiver (Fan-In) side

Find Products Catalog

Problems Solved

Reliably routing the input signal to any output port, Switch Matrices are applicable for complex applications where multiple I/O signals increase switching complexity.

  • Situations where high-density RF switching (transmitting and receiving) for narrowband, low frequency and low power applications are required
  • Support for low power and high-density signal routing both on the transmitter (Fan-Out) and receiver (Fan-In) side
