ICE 3006

MPG Solutions ICE3006 is an agile filter/amplifier cascade for the UHF frequency band with a VHF bypass


ICE3006_648x432

Overview

Product SKU ID :

Product Name : ICE 3006

MPG Solutions ICE 3006 is an agile filter/amplifier cascade for the UHF frequency band with a VHF bypass. It enables simultaneous operation of multiple transceivers in the cosite environment.

MPG_Modular_Badge-140x100

MODULAR

MPG_SWaP_Badge-140x100

SWAP

MPG_Custom_Design_Badge-140x100

CUSTOM DESIGN

Problems Solved

It enables simultaneous operation of multiple transceivers in the cosite environment. This filter/amplifier provides multiple poles of RF selectivity to reduce broadband noise, harmonics, and spurious signals while still providing full output power in transmit mode and excellent selectivity to interfering signals at the transceiver’s RF input in receive mode. All transmit, receive, and bypass switching is incorporated into the three-port design (LOS and SATCOM).

Applications

MPG Solutions are qualified for airborne platforms and ground mobile or shipboard communication systems. Our flexible solutions support multiple radio models, including ARC-225, ARC-231, ARC-210 and ARC-210D radios, providing built in agility to simplify future integrations with new technology.

Markets

Communications Defense

ICE3006_648x432

Product Specifications

Frequency Coverage

Receive Gain


RF Output Power

Size Weight
30 – 174 MHz Bypass 225 – 400 MHz AM/FM Rx/Tx

Have Quick (HQ)/HQ II

400 – 406.025 MHz AM/FM Receive only and automatic bypass

7.0 to 11.0 30W (AM) 110W (FM/FSK 225-400 MHz) 125W (FM/PSK 292-318 MHz) 9 x 6 x 19.3 / 228 x 152 x 491 26.2 lbs. / 11.88 kg

Resources

Featured Brand

PZ_Logo

Pole/Zero

Through continuous product, technology, and process innovation, Pole/Zero continues to expand its role as the leading supplier of unique, cost-effective solutions to the most complex of RF challenges. Our comprehensive suite of RF interference mitigation devices includes Tunable Filters, Low Noise Amplifiers, Integrated Cosite Equipment, Cosite Power Amplifiers and a wide range of other products tailored to the interference characteristics of multiple industries.

Our expertise and experience in space and military markets, has led to industry leading products that readily meet the unique size, weight and power requirements of cosite environments, placing us as a leading supplier for military applications.
