WSD-00357

SMR & ESMR / Public Safety Duplexer

Overview

Product SKU ID :

Product Name : WSD-00357

15 MHz Passbands: 806-821 & 851-866 MHz

Highly Selective Bandpass Response for Both Channels

High Isolation

Compact Dimensions: 7.5" x 6.0" x 2.75" (excluding connectors)

iDEN or Public Safety Micro or Repeaters

MODULAR

SWaP

CUSTOM DESIGN

Request For Quote

Applications

Delivering versatile high performance, our Duplexers are applicable for multiple markets, including defense, EW and RADAR.

Markets

Defense Communications

Product Specifications

WSD-00357 Passbands		WSD-00359 Passbands		Passband Insertion Loss		Passband Amplitude Flatness		Passband Return Loss
LOW	HIGH	LOW	HIGH	WSD-00357	WSD-00359	WSD-00357	WSD-00359
806 - 821 MHz	851 - 866 MHz	806 - 824 MHz	851 - 869 MHz	2.0 dB max	4.0 dB max	1.4 dB p-p max.	3.5 dB p-p max.	15 dB min.
