Product Name: EW 454-01
This C Band filter is ideal for use in the front end of C Band receivers or as an IF filter within a superhet receiver. It also offers good isolation over the entire military spectrum.
Because of the rugged package design, small size, high Q, and temperature stability, K&L Microwave’s Suspended Substrate Filters can fit a wide range of applications, including those in the following markets: defense, EW, radar, communications, satcom, telecom, SIGIN, aerospace, space, automated test equipment, navigation/GPS and data links.
Rejection from DC to 2.505 GHz
|Rejection from 9.1 to 18.0 GHz|
|3.94 to 8.04 GHz||1.5 dB max||12 dB min||50 dB min||50 dB min||+20 dBm max|
0 to 50°C
