RADAR 466-01

Overview

Product SKU ID:

Product Name : RADAR 466-01

Ideal for integrating into X Band waveguide transmitter assemblies, this harmonic filter provides over 40 dB of harmonic rejection and 8 kW of peak pulse power handling.

MODULAR

SWaP

CUSTOM DESIGN

Request For Quote

Applications

Whether you’re choosing one of MPG’s packaged or custom designs, RF Waveguide filters can fit a range of narrow band, high frequency applications, including those in the following markets: defense, EW, radar, communications, satcom, telecom, SIGIN, aerospace, space, automated test equipment, navigation/GPS and data links.

Market

Defense Aerospace Communications GPS

Product Specifications

Passband	Insertion Loss	Return Loss	Rejection from 17.8 to 19.0 GHz	Power Handling	Operating Temperature	Connectors	External Finish
8.9 to 9.5 GHz	0.15 dB max	20 dB min	40 dB min	8 kW max	-40 to 85°C	UBR100 Flange	Matt Black
