Product Name: EW 455-01
This S Band filter is ideal for use in the front end of X Band receivers. It also offers good isolation over the entire military spectrum up to K Band.
Because of the rugged package design, small size, high Q, and temperature stability, K&L Microwave’s Suspended Substrate Filters can fit a wide range of applications, including those in the following markets: defense, EW, radar, communications, satcom, telecom, SIGIN, aerospace, space, automated test equipment, navigation/GPS and data links.
Rejection from DC to 6.9 GHz
|Rejection from 15.9 to 26.0 GHz|
|7.96 to 14.04 GHz||1.5 dB max||12 dB min||50 dB min||50 dB min||+20 dBm max|
0 to 50°C
BSC is based in York, UK, BSC offers its full range of non-ITAR products to the RF global marketplace, whether for small quick turn development runs or high volumes associated with series production of phased array RADAR and EW systems and commercial market place needs. A small selection of the active microwave assemblies and modules offered include front end preselectors, Switched Filters for Antenna front ends, IF assemblies, DRFM front ends, adaptive filtering including switched multiplexers, switched filter banks, and Software Defined Radio filter assemblies.
