TCOM 424-01

Overview

Product SKU ID :

Product Name : TCOM 424-01

BSC have a wide range of components that have been designed for the Telecom Industry. The TCOM 424 filter offers a spot frequency passband for DCS / GSM 1800 cellular telephony transmitters or DCS telephony jammers with up to 50 W power handling capability.

MODULAR

SWaP

CUSTOM DESIGN

Request For Quote

Applications

Due to the durable packaging and high performance, K&L Microwave Combline Filters are ideal for a variety of applications, including those in the following markets: defense, EW, radar, communications, satcom, telecom, SIGIN, aerospace, space, automated test equipment, navigation/GPS and data links.

Markets

Defense Aerospace Communications GPS

Product Secifications

Passband	Insertion Loss	Return Loss	Rejection from 1.845 to 1.88 GHz	Power Handling	Operating temperature	Connectors	External Finish
1.8845 to 1.9 GHz	3.0 dB max	16 dB min	50 dB min	50 W max	15 to 40°C	SMA Female	Matt Black

Resources

Pole/Zero ICE Product Catalog

View

BSC Filters Brochure

View

K&L Microwave Filters Product Catalog

View

Tunable Filters Brochure

View

Access Filter Wizard

Visit

Access QuEST

Visit

View All

Featured Brand

BSC

BSC is based in York, UK, BSC offers its full range of non-ITAR products to the RF global marketplace, whether for small quick turn development runs or high volumes associated with series production of phased array RADAR and EW systems and commercial market place needs. A small selection of the active microwave assemblies and modules offered include front end preselectors, Switched Filters for Antenna front ends, IF assemblies, DRFM front ends, adaptive filtering including switched multiplexers, switched filter banks, and Software Defined Radio filter assemblies.

Learn More Find Products
