CERAMIC BANDPASS FILTER

TCOM 423-01

Overview

Product SKU:

Product Name: TCOM 423-01

BSC have a wide range of components that have been designed for the Telecom Industry. The TCOM 423 filter offers a passband for DCS / GSM 1800 cellular telephony transmitters. Downlink frequencies are protected by over 50 dB of isolation.

MODULAR

SWaP

CUSTOM DESIGN

Request For Quote

Applications

K&L RF Ceramic Filters offer high-quality performance in a small package size, making them ideal for tight configurations, including those in the following markets: defense, EW, radar, communications, satcom, telecom, SIGIN, aerospace, space, automated test equipment, navigation/GPS and data links.

Markets

Defense Aerospace Communications GPS

Product Specifications

Centre Frequency	Insertion Loss at Centre Frequency	1 dB Passband	Return Loss	Rejection from DC to 1.72 GHz	Rejection from 1.98 to 8.0 GHz	Power Handling	Operating temperature	Connectors	External Finish
1.8425 GHz	3.0 dB max	1.805 to 1.88 GHz	14 dB min	50 dB min	50 dB min	2 W CW max	-10 to 50°C	SMA Female	Matt Blac
