SPDT High Power Coaxial Switches
MPG 's High Power Coaxial SPDT Switch routes a signal to one of two outputs. Designed specifically for military applications.
Overview
MPG's High Power Coaxial SPDT switch offers low insertion loss and fast switching, but reliable use can be challenging. A high power switch acts as a two terminal device, meaning that the control port utilized for biasing and the port used for the RF signal are one and the same. To ensure proper functioning and fit, our experienced engineers work individually with customers to tailor the design and manufacture of each high power switch to exacting specifications..
Special Features
Designed to reliably route microwave signals or RF energy from point to point within a transmission line, MPG's High Power Coax SPDT Switches are equally at home in an industrial environment, such as large RF communication systems and networks, or within the lab supporting RF testing equipment.
Our technical team and experienced engineers will help you determine the optimal High Power Coax SPDT Switch or Coax Relay solution for your needs from our extended line of off-the-shelf and custom-designed products.
MPG Sales
Ordering Information
Parts & Quotes
- Please request a quote on a specific designs.
- When considering a particular family of parts, use Filter Wizard and QuEST to determine specific part number.
Features & Specifications
Our full line of High Power Coax SPDT Switches or Coax Relays can be purchased or purpose-built to the following specifications:
High Power Coax SPDT Switch frequency:
Coaxial Switches route RF signals over a broad bandwidth from DC - 12.4 GHz
High Power Coax SPDT Switch features:
Our High Power Coax SPDT Switches support maximum VSWR ranging from 1.1 to 1.95 with minimum isolation ranges from 55 dB to 85 dB and a max insertion loss from .1 dB to .8 dB, depending on configuration.
High Power Coax SPDT Switches can be designed to meet customer specifications across the following ranges:
- Operating Voltage (across temperature range): 28 Vdc (20-30 Vdc)
- Switching time: 20 ms max.
