Lumped Element Fixed High Pass Filters

Overview

Thanks to durable standard packaging and our team of experienced engineers, K&L Microwave can provide customized Lumped Element Filters (LC Filters) at a reduced time to market. Standard packages are available for most applications, including those where severe environmental stresses, such as temperature, humidity, shock, vibrations and acceleration are common. HF, VHF and UHF in bandpass, band reject, high pass and low pass designs.

Frequency Range: : 0.5 MHz to 10 GHz

Bandwidth: 1% to 200%

Find Products Catalog

About The Technology

Lumped Element

LC filters are passive devices, smaller than the operating wavelength, to permit a wider bandwidth within compact packaging. Special design capabilities for our Lumped Element Filters include, but are not limited to, elliptical, pseudo-elliptical, amplitude equalization, group delay equalization, bessel, gaussian, and highpower.

Product Inquiry

Featured Brands

K&L Microwave

BSC

Features & Specifications

Lumped Element Filter frequency: HF, VHF and UHF from 0.5 MHz to 10 GHz (L band, S band, C band, X band)

Lumped Element Filter features: LC Filters are available in bandwidths from 1% to 200%, in configurations of 2 to 10 sections. Filters are available in a Q range of 400 to 800 with bandpass, band reject, high pass and low pass designs available.

Benefits

MODULAR

SWaP

CUSTOM DESIGN

Applications

Due to the innovative and customizable nature of MPG's Lumped Element Filters, they can fit a wide range of applications, including those in the following markets: defense, EW, RADAR, communications, SATCOM, telecom, SIGINT, aerospace, space, automated test equipment, navigation/GPS and data links.
