ERF | Extended Range Tunable Band Pass Filters

Overview

MPG’s series of Extended Range Filters (ERF™) combine a highly tunable interface with consistent power handling inside a modest package, fulfilling the need for a small and rugged RF filtering device.

Frequency Range: VHF-L, VHF-H or UHF from 1.5 MHz to 520 MHz.

Bandwidth: 3%-10%

Find Products Catalog

About The Technology

ERF

MPG’s ERF filters tune using either Parallel or Serial Peripheral Interface (SPI) tuning control. All ERF filters are fully pre-aligned by MPG for added savings and convenience and designed to meet multiple low power, high-performance specifications, including those required for military handheld radios, RADAR systems, SATCOM, test and measurement systems and additional commercial applications.

Product Inquiry

Featured Brand

POLE/ZERO

Features & Specifications

HF-ERF™ has the best insertion loss and Q in the smallest industry available package

Fully tested and aligned by MPG for convenience and ease of use

Modified variants are available upon request, affording versatile customization

Frequency:VHF-L, VHF-H or UHF from 1.5 MHz to 520 MHz.

Features: ERF Tunable Filters are available in bandwidths from 3% to 10% with insertion loss of 2.51 to 5 dB.

Benefits

MODULAR

SWaP

CUSTOM DESIGN

Application

Delivering high performance in a small package, MPG’s ERF Tunable Filter is applicable for multiple markets, including defense, EW, RADAR, communications, SATCOM, and automated test equipment.
