Helical Fixed Band Pass Filters

Overview

MPG’s RF Helical Filters are ideal for applications utilizing a narrow frequency range and where low insertion loss and impedance is required. VHF and UHF in band pass configurations.

Frequency Range: 45 MHz to 3 GHz

Bandwidth: 1% to 3%

Find Products Catalog

About the Technology

Helical Filters

MPG products are open frame, surface mount Ceramic Filters, designed for applications requiring superior temperature stability and high Q response.

Product Inquiry

Featured Brands

K&L Microwave

BSC

Features & Specifications

RF Helical Filter frequency: VHF and UHF from 45MHz to 3 GHz (L band)

RF Helical Filter features: RF Helical Filters are available in bandwidths from 1% to 3%, and configurations of 2 to 6 sections. RF Helical Filters are available in a Q range of 600 to 1000 in a bandpass configuration.

Frequency: VHF and UHF from 45MHz to 3 GHz (L band)

Features: RF Helical Filters are available in bandwidths from 1% to 3%, and configurations of 2 to 6 sections. RF Helical Filters are available in a Q range of 600 to 1000 in a bandpass configuration.

Benefits

MODULAR

SWaP

CUSTOM DESIGN

Applications

RF Helical Filters provide a high Q low loss filter ideal for the following markets: defense, EW, RADAR, communications, SATCOM, telecom, SIGINT, aerospace, space, automated test equipment, navigation/GPS and data links.
